一鍵關機控制 關機時只需旋轉一下鑰匙，設備自動安全關機，減少設備故障。環保設計 鉛簾外加保護膜，防止客人手接觸鉛，避免鉛污染。動態畫面切換 畫面在靜止的時候可以切換，在動態的時候也可以自如切換。
獨有特點：
一鍵關機控制 關機時只需旋轉一下鑰匙，設備自動安全關機，減少設備故障。
環保設計 鉛簾外加保護膜，防止客人手接觸鉛，避免鉛污染
動態畫面切換 畫面在靜止的時候可以切換，在動態的時候也可以自如切換。
Unique features：
One key shutdown control When shutting down, just turn the key, the equipment automatically and safely shut down, reducing equipment failure.
Environmental protection design Lead curtain plus protective film to prevent guests' hands from contacting lead and avoiding lead pollution
Dynamic screen switching The screen can be switched when it is stationary, and it can be switched freely when it is dynamic.
基本參數指標：
通道尺寸 500（寬）×300（高）mm
傳送帶速度 0.22m/s
傳送帶額定負荷 150 kg（170kg）
穿透力 大于11mm鋼板（43mm）
通過率 720個/h
線分辨力 直徑0.0787mm金屬絲
穿透分辨力 直徑0.127 mm 金屬絲
空間分辨力 水平：直徑1.0 mm 垂直：直徑1.0 mm
膠卷安全性 對ISO1600膠卷安全
Basic parameter indicators:
Channel size 500(W)×300(H)mm
Conveyor speed 0.22m/s
Conveyor belt rated load 150 kg (170kg)
Penetration force Greater than 11mm steel plate (43mm)
Passing rate 720 pcs/h
Line resolution Diameter 0.0787mm metal wire
Penetration resolution Diameter 0.127 mm metal wire
Spatial resolution Horizontal: 1.0 mm diameter Vertical: 1.0 mm diameter
Film Security Safe for ISO 1600 film
輻射安全：
單次檢查劑量 小于1μGγ
泄露射線劑量率 小于0.3μGγ/h （在距設備外表面5cm的任意處測試均符合且優于國內外健康安全標準）
高效防輻射 雙層錯縫布置耐磨、結實的鉛簾，超厚2-5mm鉛板封堵X射線泄露輻射
Radiation safety:
Single inspection dose Less than 1μGγ
Leakage radiation dose rate Less than 0.3μGγ/h (tested at any place 5cm from the outersurface of the equipment is in line with and better than domesticand international health and safety standards)
Highly effective radiation protection Double-layer staggered arrangement of wear-resistant, strong lead curtains, extra-thick 2-5mm lead plates to seal X-rays Leakage of radiation
X射線發生器：
數字接口 管電壓80-160KV（可調），電流0.3-1.2mA（可調）
冷卻／工作周期 密封式油冷／100％
X-ray generator:
Digital interface Tube voltage 80-160KV (adjustable), current 0.3-1.2mA (adjustable)
Cooling / working cycle Sealed oil cooling / 100%
設備功能：
圖像處理功能 彩色/黑白、局增、超增、邊緣增強、灰掃、高穿、低穿、增亮、減暗、放大/縮小、回拉/前拉（有機物剔除、無機物剔除、反色、偽彩、有機物增強、可疑物品報警標記）
系統功能 開機自檢、多級用戶管理、圖像管理、TIP管理、曲線診斷、系統設備信息、圖像鏡像、1-16（1-64）倍無極放大、操作員培訓、精準定位過包圖像、清空通道提醒、設備信息查詢、快速切換 語言、U盤升級軟件、遠程實時查看圖像、一件校準,一鍵關機、智能滾筒（選配）
Equipment functions:
Image processing functions: color / black and white, bureau increase, super increase, edge enhancement, gray sweep, high penetration, low penetration, brightening, darkening, enlargement / reduction, pull back / pull forward (organic rejection, inorganic rejection, inverse color, pseudo color, organic enhancement, suspicious items alarm mark)
System functions: self-test, multi-level user management, image management, TIP management, curve diagnosis, system equipment information, image mirroring, 1-16 (1-64) times infinite magnification, operator training, accurate positioning of overpacked images, empty channel reminder, equipment information query, fast language switching, U disk software upgrade, remote real-time image viewing, one piece calibration, one key shutdown, intelligent roller (optional)
結構設計：
機架 融合工業設計理念，防銹、防腐、防線纜損傷、莊重穩固。
防夾手裝置 通道進出口的皮帶下方及接物架獨特防夾手設計、安全可靠。
優質皮帶 輸送帶表面鉆石紋面印花、使用中更耐切割、耐刮花；2mm厚度更耐拉伸，不易變形；表面防靜電處理，使用時不易被污染。
立體指示燈 四角立住指示燈，全角度及時顯示設備工作狀態，外形簡約美觀（選）
人性化設計 專業鍵盤，配合符合人體工程學設計的工作臺，使用便捷，舒適（選）
Structure design:
Rack Integration of industrial design concept, rust-proof, anti-corrosion, anti-cable damage, stately and solid.
Anti-pinch device Unique anti-pinching design under the belt at the entrance and exit of the channel and the receiving frame, safe and reliable.
Quality belts The surface of the conveyor belt is printed with diamond pattern surface, which is more resistant to cutting and scratching in use; the 2mm thickness is more resistant to stretching and not easily deformed; the surface is anti-static treated, which is not easily contaminated in use.
Stereo Indicator Light standing at four corners, full angle timely display of equipment working status, simple and beautiful appearance (optional)
Humanized design Professional keyboard, with ergonomic design of the workbench, easy to use, comfortable (optional)
安裝數據：
外形尺寸（不含接物架） 1660mm（長）*746mm（寬）*1165mm（高）
（1664mm（長）*746mm（寬）*1148mm（高）
Installation data:
Overall dimensions (without receiving shelf) 1660mm (L)*746mm (W)*1165mm (H)
(1664mm (L)*746mm (W)*1148mm (H)
使用環境：
工作溫度／濕度 0℃～45℃／20%～95% (不冷凝)
儲存溫度／濕度 -20℃～60℃／20%～95% (不冷凝)
工作電壓 220VAC(±10%) 50±3HZ
功率損耗 0.5KW
噪聲級 55dB（A）
Operating environment:
Operating temperature / humidity 0℃～45℃／20%～95% (non-condensing)
Storage temperature / humidity -20 ℃ ~ 60 ℃ / 20% ~ 95% (non-condensing)
Working voltage 220VAC(±10%) 50±3HZ
Power loss 0.5KW
Noise level 55dB(A)
